Smart Tripod Turnstile Gate with Face Recognition & QR Code Scanner - Anti-Collision Pedestrian Access Control Barrier System
Classification :
PRODUCT DETAILS
Baroxon Ba-602 High-End Intelligent Pedestrian Gate - Premium Access Control Solution for the Philippines
The Baroxon Ba-602 is a state-of-the-art Automatic Turnstile Gate solution designed specifically to meet the standards of modern commercial buildings, industrial factory areas, and public transportation hubs in the Philippines. Built with a robust 304 Stainless Steel chassis, this security barrier offers high flexibility for integration with ESD Systems and advanced Face Recognition scanners, ensuring maximum safety and smooth pedestrian traffic flow across Metro Manila, Cebu, and Davao regions.
Key Attributes - Ba-602 Specifications
| Protection Level | IP55 | Barrier open/close time | 0.2 s, 0.4 s |
| Barrier Motor | Baroxon Brushless Motor | Access Control Type | ESD System, Face Recognition, Fingerprint, QR Code, RFID Card, IC Card |
| Turnstile Function | Anti-Pinch, Anti-Tailgating, Collision Avoidance, Counting Function | Operation Direction | 2-Way (Bi-directional) |
| Communication Interface | TCP/IP, RS485 | Material | 304 Grade Stainless Steel |
| Brand Name | Baroxon | Model Number | Ba-602 |
Video Demo: Operational Intelligent Swing Barrier Gate Mechanism and Speed Validation Test for Baroxon Ba-602 Philippines
Technical Specification - Detail
| Housing Material | 304 grade stainless steel |
| Size | L420*W330*H980mm |
| Thickness | 1.50mm thickness |
| Working Voltage | AC220±10% V / 50±10% HZ |
| Pass Speed | 40 persons/min (open) |
| Operating Temperature | -30℃ ~ +70℃ |
| Passage Width | 550mm (Arm length 500mm) |
Movement Controller Features - Key Advantages:
* Outdoor swing brake mechanism featuring proprietary Shandong Baroxon multi-layer safety technology: "Infrared Anti-Clip + Mechanical Anti-Clip + Current Detection Anti-Collision".
* Multi-point composite infrared control logic equipped with advanced Anti-Tailgating and Anti-Submarine features.
* Intelligent voice broadcasting module for easy maintenance and mechanical status reporting.
* High-visibility three-color LED indicator lights (Blue, Green, Red) for modern aesthetics and intuitive pedestrian path guidance.
* Configurable barrier open/close speeds to optimize traffic flow based on your building's footfall requirements.
* Accurate Counting Function to support visitor management databases.
* Flexible communication interfaces: RS232, Can, I/O, and RS485.
* Selectable traffic modes: Normally Open (NO) or Normally Closed (NC).
* Integrated Fire Escape Input Interface for automated gate opening during emergencies.
Packaging & Logistics - Philippines Export Standard
| Selling Units | Single item | Single package size | 150X150X150 cm |
| Single gross weight | 300.000 kg | Standard | Heavy Duty Wooden Crate |
Customer FAQ
Q1: Is the Baroxon Ba-602 suitable for outdoor use in the Philippines?
A: Yes. With IP55 protection and SUS304 stainless steel, it is highly resistant to heat and humidity. We recommend a protective canopy for areas with heavy rainfall to ensure long-term durability.
Q2: Can this gate integrate with our local HR attendance software?
A: Absolutely. Our Security Access Control systems utilize standard TCP/IP and RS485 interfaces, making them fully compatible with most HRMS and attendance software used by Philippine corporations.
Q3: How about product warranty and after-sales support?
A: We provide comprehensive technical support. Our team offers remote online guidance and can deploy technical experts to your project site in Metro Manila or across the Philippines for calibration and maintenance.
Q4: How long is the lead time for shipping to Manila?
A: Manufacturing takes 10-20 working days. Shipping duration depends on the logistics provider, and we guarantee secure export-grade wooden pallet packing to prevent any transit damage.
