Manual Swing Security Traffic Barrier with Optional Automation Kit - Heavy-Duty Perimeter Vehicle Access Control Gate for Philippine Facilities
Classification :
PRODUCT DETAILS
Key Technical Specifications - Baroxon Automated Traffic Systems
| Access Type | RFID Card, Password, Remote Key, Bluetooth Mobile, UHF Tag | Special Features | Anti-Collision Rebound, Built-In Siren, Motion Detection, Night Vision, Attendance Log |
| Data Storage | Cloud Server, Memory Card | Housing Material | Cold-rolled Steel, Stainless Steel, Zinc Alloy Components |
| Place of Origin | Shandong, China | Model Number | YH-PDPY601 |
| Brand Name | Baroxon | Motor Drive Type | DC 24V Brushless / AC 220V / Servo Motor Inverter |
| Duty Cycle | 100% / Continuous / 5000 cycles per day | Opening/Closing Speed | 0.6s / 0.9s / 1.5s - 6s (Adjustable) |
| Boom Arm Profile | Straight / Folding (90°/180°) / Fence (Two/Three-rail) | Arm Span Range | 1m - 6m (Customizable) |
| Power Consumption | Peak: 140W / Standby:<5W | MCBF | 3 million / 5 million / 10 million cycles |
| Chassis Construction | 2.0mm Cold-rolled Steel / Powder Coating | MTTR | < 30 mins |
| Protection Class | IP54 / IP65 / IP66 |
Packaging and Shipping Logistics
| Selling Unit | Single unit, international export standard wooden pallet crate package with protective foam |
Baroxon provides top-tier automated gate security solutions through our automatic parking barrier gate system network, equipped with integrated intelligent control motherboards for highly responsive RFID reader data processing across commercial properties in Manila and provincial hubs.
The modular construction of our commercial parking barrier gate lineup features exceptional physical resilience optimized for swift field deployment while cutting down long-term maintenance costs for industrial and residential estates.
Smooth operational performance is fully backed by heavy-duty DC brushless motors and automatic frequency conversion inverter technology, rendering it the ideal choice for high-frequency corporate driveways and tollways.
Active security is sustained by smart anti-collision circuits and mechanical auto-rebound sensors, coupled with universal compatibility alongside advanced alpr lpr system computer vision camera software.
Product Demonstration & Cycle Testing Videos
Structural Photos & Component Breakdown Details
About Baroxon - Leading Traffic Barrier Gate Manufacturer
As a primary manufacturing pioneer in global physical perimeter security systems, Baroxon specializes in offering integrated technical solutions and mass production of professional vehicle access control equipment to support modern public infrastructure networks.
Competitive Market Strategy: Dedicated engineering focus on heavy-duty straight arm automated barriers, electric fence security gates, and seamless smart parking software integration.
International Deployment Footprint: Trusted by property management executives, civil contractors, and parking operators across the Philippines, USA, UK, Canada, and Australia.
Comprehensive Project Technical Support: Providing complete site survey services, wiring blueprint schematics drafting, installation technician training sessions, and periodic consultations.
Modular Mechanical Architecture: All internal cabinet assemblies are precision-engineered to facilitate smooth on-site deployment and maximize equipment lifespan across any outdoor environment.
Independent Patent Innovation: Holding an extensive intellectual property portfolio comprising over 100 industrial patents covering DC brushless motor control circuits and safety detection logic.
Experienced R&D Management Team: Research divisions and production hierarchies are supported by over 20 years of practical industry expertise within access control automation markets.
Prime Service Guarantee Commitment: Delivering rapid digital customer support responses within 60 seconds, emergency technical evaluations within 2 hours, and guaranteed issue resolution within 2 days.
Manufacturing & Customization
Frequently Asked Questions (FAQ)
Q1: What are the configurable opening and closing speeds of the system?
A: Our electric portal devices support flexible movement tuning options ranging from ultra-fast speeds of 0.6s, 0.9s, up to 1.5s - 6s (Adjustable). These high-acceleration speeds are ideal for automated toll gates or busy logistics warehouse entrances.
Q2: Can this automated barrier gate package operate independently via a solar panel power supply?
A: Yes, it can. The Baroxon cabinet drive unit runs on an energy-efficient low-voltage DC 24V brushless motor. The main controller board is fully ready to connect directly to storage battery banks powered by outdoor solar panels.
Q3: What is the maximum boom arm span supported by this cabinet chassis?
A: Our heavy-duty internal architecture is built to withstand high-strength lightweight aluminum arm profiles ranging from 1m up to a customizable 6m maximum span, available in straight arms, folding elbow basements, or fence barrier configurations.
Q4: Can this electric portal cabinet integrate directly with local manless parking ticket dispensers?
A: Fully compatible. The main electrical board provides standard industrial dry contact terminals, RS485 communication data connections, and Wiegand protocols. The system integrates smoothly with UHF RFID long-range readers, automatic ticket boxes, induction loop sensors, and license plate capture cameras.
Q5: How does the exterior cabinet housing withstand tropical corrosion and rust?
A: The outer protective casing is built using robust 2.0mm cold-rolled steel plates with international IP54 / IP65 / IP66 weatherproofing certifications. The entire body is finished with a specialized anti-UV powder coating to prevent rust from outdoor humidity.
Q6: What active safety sensor modules come included as standard features?
A: The device is equipped with intelligent auto-rebound current detection circuitry that immediately reverses the boom arm direction upward if an obstacle is detected underneath. Infrared photocell sensors, inductive loop detectors, and a manual clutch override release lever for power outages are also included.
Q7: What is the estimated threshold for internal mechanical cycle durability?
A: Supported by high-precision anti-wear sinusoidal transmission gears and stable brushless drive motors, this cabinet system is engineered to achieve an MCBF rating between 3 million, 5 million, up to 10 million cycles without requiring frequent servicing.
Direct Factory Inquiries
Contact Baroxon wholesale manufacturing departments for contractor partnerships, commercial project tenders, and custom pricing offers: E-mail: [email protected] | WhatsApp: +8613405313100 | WeChat: +86 18660196023
